Typical Applications

1.Raw material: other ceramic fiber based product forms such as: •

High-temperature boards, felts, and papers

2.General insulation: as infill for the roofs and walls of certain types of furnaces and kilns.

3.Packing: expansion joints, patching and emergency repairs in furnaces, boilers, heaters, etc.

4.Sealing: around penetrations in furnace, heaters and boiler walls, e.g. tubes, burners and sight holes.

Industry-specific attributes

Thickness: 6-60mm

Width:610/1220mm

Chemical Composition: Al2O3≥44,SiO2≥52,Fe2O3+TiO2≤1,K2O+Na2O≤1

Ultimate Strength (≥ MPa) 0.075

Density (kg/m³ ) 96

Other attributes

Place of Origin: Hebei, China

Application: Liners Of Industrial Furnace

Length:7320/3810mm

Working Temperature:1260

Fiber Diameter:3.5um

Shrinkage (1800 ℉, 3h)

1000℃ *24h≤2.5

Thermal Conductivity:≤0.153

Raw material: Alumium Silicate

Material: Al2O3 45%

Color:White Pure

Package: Woven Bag/Carton

Type:1100C/1260C/1420C/1600C

Feature: Heat Resistant Insulation

Bulk Density:64/80/96/128/160kg/m3

Certificate:ISO9001:2000
